Vertical Autoclave ALB582

Vertical Autoclave is designed for effective and reliable high-pressure steam sterilization with a 50 L chamber capacity. It operates within a temperature range of 105°C to 136°C and features a counter-pressure protection mechanism to prevent deformation or damage to sensitive loads. Pre-programmed sterilization cycles enable convenient and customizable operation. A high-resolution touchscreen display provides clear visualization and monitoring of operating parameters. Laboratory Equipment from Atico Exports.

• Sterilization of liquid media
• Laboratory glassware
• Laboratory instruments
• Laboratories
• Research institutes
• Pharmaceutical industries
• Medical facilities

Capacity :

• 50 L

Chamber Dimensions :

• Φ 316 × 667 mm

Temperature Range :

• 105 to 136℃

Maximum Working Temperature :

• 136℃

Temperature Accuracy :

• 0.1℃

Temperature Uniformity :

• ≤ ±0.5℃

Maximum Working Pressure :

• 0.23 MPa

Design Pressure :

• 0.3 MPa

Design Temperature :

• 150℃

Display :

• Touchscreen

Power Supply :

• AC 220–240 V / 50–60 Hz

Product Dimensions :

• 476 × 636 × 990 mm

Packaging Dimensions :

• 700 × 680 × 1140 mm

Net Weight :

• 86 kg

Gross Weight :

• 102 kg
  Standard Accessories :
• Basket × 2 Pcs
• Hose × 1 Pc
• F₀-Style Counter Pressure
• Built-in Printer

Optional Accessories :

• 30 L Air Compressor

• Counter-pressure protection
• Uniform heat distribution
• Air cooling system
• Over-temperature protection
• Atmospheric pressure correction
• Cycle-end buzzer alert
• Automatic sterilization cycle
• Anti-dry heating alarm
• Pre-programmed sterilization cycles
• High-resolution touchscreen display
• Reliable sterilization performance
