Vertical Autoclave ALB589

Vertical Autoclave is designed for precise and reliable high-pressure steam sterilization with an 80 L chamber capacity. It operates within a temperature range of 105℃ to 136℃ and features an air-cooling system for safe and rapid reduction of the internal temperature after sterilization. The unit incorporates a counter-pressure protection system to protect the structural integrity of sterilized items. A touchscreen display enables convenient monitoring and control of operating parameters. Laboratory Equipment from Atico Exports.

• Sterilization of medical instruments
• Laboratory glassware
• Culture media
• Liquid loads
• Hospitals
• Research laboratories
• Pharmaceutical industries
• Microbiology laboratories

Capacity :

• 80 L

Chamber Dimensions :

• Φ 386 × 700 mm

Temperature Range :

• 105 to 136℃

Maximum Working Temperature :

• 136℃

Temperature Accuracy :

• 0.1℃

Temperature Uniformity :

• ≤ ±0.5℃

Maximum Working Pressure :

• 0.23 MPa

Design Pressure :

• 0.3 MPa

Design Temperature :

• 150℃

Display :

• Touchscreen

Power Supply :

• AC 220–240 V / 50–60 Hz

Product Dimensions :

• 546 × 710 × 1030 mm

Packaging Dimensions :

• 870 × 790 × 1320 mm

Net Weight :

• 96 kg

Gross Weight :

• 124 kg

Standard Accessories :

• Basket × 2 Pcs
• Hose × 1 Pc
• F₀-Style Counter Pressure
• Built-in Printer

Optional Accessories :

• 30 L Air Compressor

• Pre-programmed sterilization cycles
• Uniform heat distribution
• Atmospheric pressure correction
• Air cooling system
• Automatic sterilization cycle
• Over-temperature protection
• Cycle-end buzzer alert
• Anti-dry heating alarm
• Counter-pressure protection system
• Touchscreen display
• Reliable sterilization performance
