Vertical Autoclave ALB614

Vertical Autoclave is designed for efficient and reliable steam sterilization with a 50 L chamber capacity. It operates within a temperature range of 105 to 134 °C and maintains temperature uniformity within ±1 °C for consistent sterilization results. The unit automatically releases cold air and steam after sterilization for safe and efficient operation. An LCD display shows the working status, while touch controls enable easy monitoring and precise operation. Laboratory Equipment from Atico Exports.

• Sterilization of surgical instruments
• Dressings
• Utensils
• Culture media
• Hospitals
• Clinics
• Laboratories
• Research facilities

Capacity :

• 50 L

Temperature Range :

• 105 to 134 °C

Maximum Working Temperature :

• 134 °C

Temperature Uniformity :

• ≤ ±1 °C

Working Pressure :

• 0.22 MPa

Maximum Working Pressure :

• 0.23 MPa

Timer Range :

• 0 to 99 min / 0 to 99 hr 59 min

Power Consumption :

• 3.0 kW

Power Supply :

• AC 220 V / 50 Hz

Interior Dimensions :

• Φ 340 × 550 mm

Exterior Dimensions :

• 520 × 490 × 1150 mm

Packaging Dimensions :

• 580 × 580 × 1250 mm

Net Weight :

• 74 kg

Gross Weight :

• 94 kg

• Stainless steel construction
• Quick-opening handwheel
• Safety interlock system
• Over-temperature protection
• Over-pressure protection
• Water cut control
• Automatic buzzer stop
• Automatic cold air release
• Automatic steam release
• LCD display
• Touch controls
• Safe and reliable sterilization performance
