Vertical Autoclave ALB619

Vertical Autoclave is designed for efficient and reliable steam sterilization with a large 100 L stainless steel chamber capacity. It operates within a temperature range of 105 to 134 °C and maintains temperature uniformity within ±1 °C for consistent and precise sterilization. The unit features a quick-opening handwheel and safety interlock system for safe and convenient operation. An LCD touchscreen display provides intuitive monitoring and precise control for enhanced user convenience. Laboratory Equipment from Atico Exports.

• Sterilization of surgical instruments
• Dressings
• Utensils
• Culture media
• Hospitals
• Clinics
• Laboratories
• Research institutions

Capacity :

• 100 L

Temperature Range :

• 105 to 134 °C

Maximum Working Temperature :

• 134 °C

Temperature Uniformity :

• ≤ ±1 °C

Working Pressure :

• 0.22 MPa

Maximum Working Pressure :

• 0.23 MPa

Timer Range :

• 0 to 99 min / 0 to 99 hr 59 min

Power Consumption :

• 4.5 kW

Power Supply :

• AC 220 V / 50 Hz

Interior Dimensions :

• Φ 440 × 650 mm

Exterior Dimensions :

• 580 × 560 × 1290 mm

Packaging Dimensions :

• 640 × 640 × 1360 mm

Net Weight :

• 105 kg

Gross Weight :

• 125 kg

• Automatic air discharge
• Automatic steam release
• Overheat protection
• Overpressure protection
• Water cut-off control
• Self-expanding seal
• Automatic buzzer stop
• Simple operation
• Mesh basket
• Quick-opening handwheel
• Safety interlock system
• LCD touchscreen display
• Safe and reliable sterilization performance
