Vibrating String Lab Experiment

This apparatus is designed to study standing waves on a stretched string and the factors affecting wave propagation. It enables investigation of the relationship between string length, tension, linear density, and standing wave frequency, while also supporting advanced experiments on vibration, sound, and electromechanical energy conversion. Physics Lab Experiments from Atico Exports.

Probe Sensitivity :

• ≥ 30 dB

Range :

• 0.98 N to 49 N

Minimum Step Value :

• 0.98 N

Length :

• 700 mm

Adjustment :

• Continuously Adjustable

Frequency Range :

• Band I: 15 Hz to 200 Hz
• Band II: 100 Hz to 2000 Hz

Frequency Measurement Accuracy :

• ±0.2%

Output Amplitude :

• Adjustable from 0 to 10 Vp-p

Oscilloscope :

• Dual-trace oscilloscope required (not included)

• Suitable for studying standing wave formation and wave propagation.
• Supports inquiry-based and research-oriented experiments in acoustics and vibration.
