Vibratory Feeder

The Vibratory Feeder is used for the uniform, continuous feeding and conveyance of pourable bulk materials and fine powders. The VIBRATORY FEEDER feeds mills, sample dividers, and particle measuring devices, and it is also suitable for other feeding tasks. Its performance, adaptability and compact design makes this device suitable for a great variety of applications. The VIBRATORY FEEDER can also be driven and controlled externally via the built-in interface. vibratory feeders guarantee reproducibly exact results and maximize the efficiency of downstream laboratory and testing devices.

FUNCTIONAL PRINCIPLE

The feed material passes through the hopper onto the conveying chute. This is made to vibrate at 50 (or 60) Hz by an electromagnetic charging vibrator. The volume flow can be infinitely adjusted. The layer height on the hopper can be adjusted in accordance with the product and need.

Applications :

• feeding, conveying

Field of application :

• agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material :

• pourable bulk materials

Material feed size :

• < 2 mm (15 mm chute)
• < 6 mm (40 mm chute)
• < 12 mm (75 mm chute)

Volume :

• flow

Time setting :

• digital, 1 - 99 min / continuous operation

Speed setting :

• digital, 1 - 99 / 0 - 5 l/min, stufenlos einstellbar

Chute width :

• 15 mm / 40 mm / 75 mm / 75/40 mm

Chute length :

• 210 mm

Hopper volume :

• 2.8 l (15 mm chute)
• 2.8 l (40 mm chute)
• 3.5 l (75 mm chute)
• 3.5 l (75/40 mm chute)

Electrical supply data :

• different voltages

Power connection :

• 1-phase

W x H x D :

• 260 x 420 x 280 mm

Net weight :

• 9,7 kg

Standards :

• CE

• Strong drive for even material feed

• Material bed level and volume flow are adjustable

• Digital speed setting

• Optional control via interface

• Digital time setting

• Conmpact control and feed unit

• Easy cleaning of the push-fit chute

• Wide range of accessories including various chutes
