Vicat Test Set - Automatic

Standards Compliance :

• COMPLIED AS PER EN 196-3, 13279-2, 480-2; ASTM C191, C187

Application :

• Automatic Vicat Apparatus is used for determination of setting time and consistency of cement, mortar, and gypsum by Vicat Method.

EN Test Set Contents :

• The EN test set consists of Automatic Vicat Device, EN Vicat Mould, Initial and Software.

ASTM Test Set Contents :

• The ASTM test set consists of Automatic Vicat Device, ASTM Vicat Mould, ASTM Needle and Software.

Optiona l Accessories :

• Needle Cleaning Device and Thermostatic Bath are available as options and should be ordered separately.

Dimensions (cm) :

• AECE2171/B - 36 ° 62 ° 58
• AECE2172/B - 36 ° 62 ° 58

Weight (kg) :

• AECE2171/B - 42
• AECE2172/B - 42

Power Supply :

• AECE2171/B - 220 V, 50–60 Hz, 1 ph
• AECE2172/B - 220 V, 50–60 Hz, 1 ph

Additional Accessories :

• Conical penetration needle °8 ° 50 mm and 100 g probe to make gypsum tests following EN and DIN specifications should be ordered separately.

• Other accessories should be ordered separately.

• The Automatic Vicat Apparatus can be programmed up to 4 different test types and can store 10 tests.
• These test values can be printed from the PC port or transferred to a computer.
• The penetration measure is read by a sensor with 0.1 mm resolution.
• The Automatic Vicat Apparatus has USB port for PC connection and display for data input and graphic/test report.
