Viscometer cement testing Rheology testing instruments by ATICO EXPORT

For enhanced data collection, the pressurized viscometer accurately determines the fluid characteristics of stimulation fluids, completion fluids, drilling fluids and cement in terms of shear stress, shear rate, time and temperature at pressures up to 2,500 PSI.

Using advanced rheology software, the system is suitable for both beginners and advanced research applications. It is designed for both field and laboratory use. A waterproof compartmentalized case with wheels provides complete portability.

Competitive Advantage:

• Optional safe high-efficiency air transfer heating system provides precise sample temperature control
• Eliminates risks associated with hot oil systems such as spilling, splashing or flashing
• Oil-free design removes hazardous materials and simplifies cleaning

Size :

• 14" × 13" × 30" (36 × 33 × 76 cm)

Weight :

• 85 lb (37.6 kg)

• Upgraded transducer provides more accurate readings at low shear rates and improved calibration
• High pressure capability up to 2,500 PSI (17 MPa)
• High temperature capability up to 500°F (260°C)
• Low shear rates as low as 0.01 s⁻¹
• Portable rugged case for easy transportation
• Rugged construction suitable for field or laboratory use
• Corrosion-resistant Hastelloy wetted parts
• Compact footprint of only 12 × 12 inches (30 × 30 cm)
• All-in-one design includes integrated heating mechanism
• Available in 115 or 230 Volt models
• Real oilfield geometry using traditional bobs and rotor for easily translatable measurements
• Shear stress range: 0 - 4,000 dynes/cm²
• Computer-controlled data acquisition through serial port or Ethernet connection
