Viscometer oil and petroleum testing instruments by ATICO EXPORT

The viscometer represents the next step in the evolution of oilfield rheology. With a sleek design and enhanced performance features, this rheometer is suitable for both laboratory and field applications.

Instrument geometry :

• True Couette coaxial cylinder

Speed accuracy :

• 0.1 RPM

Motor speeds :

• 8 fixed speeds (600, 300, 200, 100, 60, 30, 6 and 3 RPM)

Readout :

• Direct dial

Power requirement :

• 115 / 230 VAC, 50/60 Hz

Power requirements :

• 12 - 24 VDC

Shipping dimensions :

• 22" × 14" × 10" (56 × 36 × 25 cm)

Shipping weight :

• 25 lb (11 kg)

• Run automated tests from an app on a phone or tablet
• Speeds are easily changed with a control knob
• Shear stress values displayed on a lighted, magnified dial for easy reading
• Motor speed continuously monitored and adjusted
• Suitable for both field and laboratory use
• Conventional oilfield rotor, bob and torsion springs maintain rheology history and reproducibility between instruments and laboratories
• Wide variety of bob and torsion springs available for different fluid tests
• Operates worldwide without flipping switches or rewiring
• Threaded rotor mechanically attaches to the unit consistently every time
