Viscometer testing instruments by ATICO EXPORT

The viscometer is a true Couette coaxial cylinder rotational oilfield viscometer that employs a transducer to measure the induced angle of rotation of the bob by a fluid sample. For fully automated control and data acquisition suitable for research applications, the viscometer can be connected to a computer via a serial port using Windows-based rheology software.

Instrument geometry :

• True Couette coaxial cylinder

Motor speeds :

• 12 fixed speeds (600, 300, 200, 100, 60, 30, 20, 10, 6, 3, 2 and 1 RPM)

Variable speed range :

• 0.006 - 1000 RPM

Speed accuracy :

• 0.001 RPM

Shear rate range :

• 0.01 - 1,700 sec⁻¹

Heat cup :

• Stainless steel, 150 Watts, maximum recommended temperature 190°F (88°C)

Power requirements :

• 97 - 250 Volts AC, 200 Watts, 50/60 Hz

Dimensions :

• 44 × 38 × 24 cm

Weight :

• 8.6 kg

Shipping weight :

• 16 kg

Shipping dimensions :

• 56 × 38 × 24 cm

• True Couette coaxial cylinder rotational viscometer
• Ability to run multiple units on one computer
• Push-button calibration history and graph functions available for improved analysis
• Single-button operations on the keypad
• Routine repairs are easily performed
• Accurate operation at extremely low shear rates down to 0.01 RPM
• Motor does not need to stop between speed changes
