Water Separability Tester for Oil Fuel and Petroleum Testing Instruments

The Water Separability Tester evaluates the ability of lubricating oils to separate from water and resist emulsification. The test involves stirring equal volumes of water and sample at a controlled temperature to form an emulsion, followed by observing the time required for separation. Suitable for petroleum oils and synthetic fluids, the instrument supports the testing of new oils and monitoring of in-service lubricants. It features a seven-position illuminated heating bath, microprocessor temperature control, and a movable digital stirrer with adjustable speed and duration. The clear polycarbonate tank provides excellent visibility of emulsion separation, while stainless steel supports securely hold the sample cylinders. The system includes digital temperature displays, over-temperature and low-liquid-level protection, automatic stirrer shutoff, and audible and visual alerts. Stored test parameters can be reused for subsequent tests, and an optional sensor is available for direct sample temperature measurement. A built-in drain and removable top plate simplify bath draining, filling, and cleaning. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant water separability testing applications.

Sample Capacity:

• Seven 100 mL graduated cylinders

Stirrer Specifications:

• Stirring speed range: 100–2000 RPM
• Speed accuracy: ±1.0 RPM
• Drive motor: 1/10 HP (75 W), high torque
• Adjustable stirring duration: Up to 99.99 minutes
• Automatic shutoff at the end of the selected interval
• Audible and visual alerts
• Backlit LCD displaying stirring speed and countdown time
• Microprocessor-controlled operation
• Pivoting stirrer housing with secure positioning
• Memory for storing test parameters

Bath Temperature Control:

• Temperature range: 25°C to 84°C
• Control stability: ±0.05°C
• Temperature control accuracy: Greater than ±1°C across the operating range
• Digital display of setpoint and actual temperature
• Selectable Celsius or Fahrenheit display
• Over-temperature and low-liquid-level protection
• Optional direct sample temperature sensor

Bath Construction:

• Clear polycarbonate tank with backlighting
• Stainless steel cylinder supports
• Protective viewing window
• Steel housing with polyester-epoxy finish
• Removable top plate
• Built-in drain

Bath Dimensions:

• 10 × 11.25 × 9.5 inches (25.5 × 28 × 24 cm)

Bath Medium:

• Water or white technical oil

Medium Capacity:

• 15.15 L (4 gallons)

Overall Dimensions (L × W × H):

• 20.75 × 15.25 × 29.5 inches (52.7 × 38.75 × 74.9 cm)

Net Weight:

• 83 lbs (37.6 kg)
