Water Washout Tester for Oil Fuel and Petroleum Testing Instruments

The Water Washout Tester is designed to evaluate the resistance of lubricating grease to water washout under controlled test conditions. A grease sample is packed into a ball bearing, which is rotated while exposed to a steady stream of water. The percentage of grease washed out during a one-hour test period is determined by weighing the bearing assembly before and after testing.

The apparatus rotates an ASTM ball bearing at 600 rpm inside a modified bearing and housing assembly while directing a controlled water jet onto the bearing. The system consists of a water reservoir, bearing housing, circulation system, and drive motor. The reservoir incorporates a cartridge heater, thermoregulator, and thermometer port to maintain the specified test temperatures of 100°F and 175°F (38°C and 79°C).

A circulation system equipped with a constant-velocity carbon-bearing gear pump, valves, and flowmeter delivers water through a 1 mm capillary spray nozzle aimed at the bearing housing. The two-pulley drive arrangement allows independent pump operation for water circulation and heating.

Manufactured by Atico Export for reliable water washout resistance testing of lubricating greases in lubricant testing and quality control laboratories.

Drive Motor :

• 1/3 hp, 1725 rpm

Test Bearing Speed :

• 600 rpm

Test Duration :

• 1 hour

Test Temperatures :

• 100°F (38°C)
• 175°F (79°C)

Temperature Control Sensitivity :

• ±1°F (±0.5°C)

Spray Nozzle :

• 1 mm capillary nozzle

Circulation System :

• Constant-velocity carbon-bearing gear pump
• Flowmeter and control valves
• Two-pulley drive arrangement

Construction :

• Reservoir with cartridge heater and thermoregulator
• Modified bearing and housing assembly
• Finished steel mounting base with locating feet

• Designed for water washout testing of lubricating greases
• Rotates the test bearing at 600 rpm
• Controlled water flow directed through a 1 mm capillary spray nozzle
• Water reservoir with cartridge heater and thermoregulator
• Test temperature settings of 100°F and 175°F
• Integrated circulation pump, valves, and flowmeter
• Two-pulley drive arrangement for independent pump operation
• 1/3 hp drive motor
• Temperature control sensitivity of ±1°F (±0.5°C)
• Steel base with locating feet for permanent benchtop installation
• Gravimetric determination of grease loss after testing and drying
