WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL)

Category: Engineering Mechanics Lab Trainers

Need Help?

Applications

This apparatus allows students to undertake two experiments within one apparatus: Work Done by a Force (Vertical) and Work Done by a Force (Tangential). The vertical back board contains one experiment on each side, thus allowing student groups to work on each experiment separately. Work Done by a Force (Vertical): The apparatus is a simple lifting mechanism with non-linear characteristics. Learn about WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL) exporters for optimal educational outcomes.. A suspension cord carrying a loaded trolley at mid span is tensioned by passing the cord over a pulley at one end and down to a weight hanger. As the vertical effort is increased, the tensioned cord will move to a new equilibrium position lifting the loaded trolley. Learn about WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL) specifications for optimal educational outcomes.. Heights of the load and effort are measured relative to the base. All the pulleys are fitted with ball bearings to minimise friction effects. Learn about WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL) suppliers for optimal educational outcomes.. Work Done by a Force (Tangential): A pivoted arm carrying a load hanger at its end is restrained by a spring balance at right angles to the arm. The angular position of the arm is indicated by a protractor scale attached to the back board. Learn about WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL) forces-hfc India for optimal educational outcomes.. The effort is the force needed to hold the weighted arm at a particular angle. This can be repeated for several different weights. Learn about WORK DONE by a VARIABLE FORCE (VERTICAL AND TANGENTIAL) equipment for optimal educational outcomes..
