Young’s Modulus Apparatus Mechanics Lab Experiments

This apparatus is designed for the measurement of Young’s Modulus of elasticity, an important parameter used in material selection and engineering design. It helps in studying the mechanical properties of various materials, including metals, optical fibers, semiconductors, nanomaterials, polymers, ceramics, and rubber. The instrument utilizes a reading microscope for direct observation and accurate measurement, making operation simple and convenient. Manufactured by Atico Export India.
Experiment:

1. Determination of Young’s Modulus

• Measure the elastic properties of materials
• Determine Young’s Modulus through experimental observation
• Study the relationship between applied load and material deformation

Reading Microscope:

Measuring Range:

• 3 mm

Division Value:

• 0.005 mm

Magnification:

• 14×

Weights:

Weight 1:

• 100 g

Weight 2:

• 200 g

Wires Provided:

Stainless Steel Wire:

• Length: Approximately 90 cm
• Diameter: 0.25 mm

Molybdenum Wire:

• Length: Approximately 90 cm
• Diameter: 0.18 mm

Accessories:

Sample Rack:

• Quantity: 1

Base:

• Quantity: 1

Three-Dimensional Seat:

• Quantity: 1

Weight Holder:

• Quantity: 1
