Young’s Modulus Apparatus Resonance Method Mechanics Lab Experiments

This apparatus is designed to study the resonance frequency of materials and determine Young’s Modulus using the dynamic suspension method. It enables the measurement and comparison of Young’s Modulus for different materials through resonance analysis. Physics Lab Experiments from Atico Exports.
1. Measurement of Resonance Frequency

• Study the resonance frequency characteristics of different materials
• Observe resonance behavior under dynamic excitation
• Analyze resonant frequency response

2. Determination of Young’s Modulus

• Determine Young’s Modulus using the dynamic suspension method
• Calculate elastic properties from resonance measurements
• Study the relationship between resonance frequency and material stiffness

3. Comparative Material Analysis

• Compare the Young’s Modulus of different materials
• Analyze variations in elastic properties
• Evaluate material characteristics through resonance testing

Technical Specifications:

Frequency Range:

• 400 Hz to 5 kHz

Display:

• Four-digit digital frequency meter
• Automatic range switching

Resolution:

• 0.1 Hz (100 – 999.9 Hz)
• 1 Hz (1000 – 9999 Hz)

Samples Provided:

• Brass
• Iron
• Aluminum

Waveform Amplifier:

• Integrated amplifier
• Resonant waveform Vp-p > 1 V
