Amott cell for spontaneous imbibition and drainage tests Instruments

The spontaneous imbibition Amott test consists of placing an oil-saturated core sample in a brine filled Amott cell. An adequate time between brine filling and sample immersion is necessary to ensure a constant, homogeneous temperature profile in the brine. The volume of oil expelled can accurately be measured by reading the graduation on the cell. The apparatus is comprised of a sealed glass container and a graduation tube located above it. Conversely, the spontaneous drainage Amott test consists of placing a water saturated core sample in an oil-filled Amott cell. An adequate time between oil filling and sample immersion is necessary to ensure a constant, homogeneous temperature profile in the oil. The volume of water expelled can accurately be measured by reading the graduation on the cell. The apparatus is comprised of a sealed glass container, a graduation tube located below it, and a stand to support the assembly. Optional high temperature Amott cells are also available.

Model 1 : Ambient temperature Amott cell

Temperature :

• ambient

Pressure :

• atmospheric

Core Diameter :

• 1 up to 2 inches

Core length :

• up to 4 inches

Graduated tube :

• 20 cc

Model 2 : High temperature Amott cell

Temperature :

• up to 120°C

Pressure :

• up to 30 psi

Core Diameter :

• 1 up to 2 inches

Core length :

• up to 4 inches

Graduated tube :

• 20 cc
