Automated core slabbing saw laboratory and Oilfield instruments

Versatile diamond impregnated radial blade utilized either to slab core samples in two halves or to trim full diameter rock samples. A variable rate feed mechanism enables the long section cuttings of ultra-high density core in one pass without fracturing, grooving or chipping, thereby producing regular high-finished surfaces.

Saw blade diameter :

• 500 mm (20'')

Maximum cutting depth :

• 150 mm (6")

Maximum core length :

• 1 meter

Compatible coolants :

• Water and oil

Power supply :

• 220VAC 1 Phases, 50 or 60 Hz, 2,200 W

Weight :

• 500 kg

Dimensions :

• 300 cm x 170 cm x 90 cm (LxHxD)
