Ball & Rod Mill with Tilting Mechanism

Ball & Rod Mill with Tilting Mechanism is designed to meet industrial requirements for grinding coal, cement and a wide variety of ores.

Construction :

• Ball & Rod Mill with Tilting Mechanism consists of Grinding bowl, 0.75 kW geared motor mounted on a high precision robust steel chassis, speed converter, suitable separation sieves and sampler.
• The drum is made of AISI 304 material.

Locking Mechanism :

• The device includes a locking mechanism to allow easy access to the contents of the mill.
• Thanks to the locking mechanism, the cylindrical axis of the device can be brought to the position exactly parallel to the ground (Grinding position) and to the fully vertical position (Mill loading and unloading position).
• The lid has a quick-release locking mechanism.

Speed Control :

• It is equipped with a speed controller to control the drum speed between 0–100 rpm.
  Timer :
• The device has a digital timer that automatically stops the grinder when the grinding time is reached.

Grinding Media :

• Grinding Ball Set (heat treated hardened chrome alloy) and Grinding Rods (AISI 304 stainless steel) must be ordered separately upon request.

Models and Drum Dimensions :

• Drum dimensions for Model Ball & Rod Mill with Tilting Mechanism, 6 lt are 200 mm - 200 mm and 6 liter capacity.
• Drum dimensions for Model Ball & Rod Mill with Tilting Mechanism, 12 lt are 250 mm - 250 mm and 12 liters capacity.
• Drum dimensions for Model Ball & Rod Mill with Tilting Mechanism, 22 lt are 305 mm - 305 mm and 22 liters capacity.

Power Supply :

• Ball & Rod Mill with Tilting Mechanism, 6 lt - 220 V, 50-60 Hz, 1 ph
• Ball & Rod Mill with Tilting Mechanism, 12 lt - 220 V, 50-60 Hz, 1 ph
• Ball & Rod Mill with Tilting Mechanism, 22 lt - 220 V, 50-60 Hz, 1 ph
