Basic Electricity Trainer

The system is a comprehensive and self-contained system specially designed for Electricity Circuit experiments in Engineering. It covers a wide variety of essential topics in the field of Electricity Circuit and is a time and cost saving device for students and researchers interested in developing and testing circuit prototypes. Experiment modules include simulation fault switches for fault-finding experiments with full documentation for instructional and experimental manual and model answers.

Experiments :

• DC Voltage Measurement
• Using an Ohmmeter
• Resistor Characteristics
• DC Current Measurement
• Ohm's Law
• Power in DC Circuit
• Series-Parallel Network and Kirchhoff's Law
• Superposition, Thevenin's and Norton's Theorems
• Maximum Power Transfer Theorem
• DC RC Circuit and Transient Phenomena
• AC Voltage Measurement
• AC Current Measurement
• AC RC Circuit
• AC RL Circuit
• AC RLC Circuit
• Power in AC Circuit
• Transformer Characteristics
• Series-Resonant Circuits
• Parallel-Resonant Circuit
• LC Filter

DC Power Supply Module

• Fixed Output: +5V/0.5A, -5V/0.5A, +12V/0.5A, -12V/0.5A
• Variable Output: +0V ~ +25V/0.5A, -0V to -25V/0.5A

AC Power Supply Module

• 19V–15V–9V–0V–9V–15V–19V

Function Generator & Clock Generator

• Sine, Triangle and Square waveform output
• Frequency range: 1Hz to 1MHz in 6 decades
• With fine adjust, Amplitude and DC offset control
• Clock output 1Hz to 1MHz in 6 decades
• Six frequency ranges:
• 1Hz to 10Hz
• 10Hz to 100Hz
• 100Hz to 1KHz
• 1KHz to 10KHz
• 10KHz to 100KHz
• 100KHz to 500KHz
• Sine wave output: 0 to 12V peak to peak variable
• Triangle wave output: 0 to 8V peak to peak variable
• Square wave output: 0 to 20V peak to peak variable

Data Switches Module

• 5 units slide switches and corresponding output terminals
• Multi Interface Adaptor Module
• Miniature Socket, 2mm Socket & 4mm Banana Adaptors

Accessories :

• 2mm Stackable Test Lead Set – 15 Units (5 Colors)
• 3 ° Digits Digital Multimeter – 1 Unit
• Instruction Manual
• Experiments Manual
• Power Cord

Additional Details :

• Power Supply: 240VAC, 50Hz (Fused Protected)
• Dimensions: (W x D x H) 310 x 260 x 90mm
• Weight: 1.5 kgs
