Benchtop core flood system and Trainers

The Benchtop core flood system and Trainers is a cost-effective and versatile solution to carry out core flooding and fluid flow studies at reservoir-representative conditions of temperature and pressure. Notably the device allows the evaluation of various secondary and tertiary EOR methods, including water flooding, polymer injection, ASP injection, miscible and immiscible gas flooding and microbial flooding. Relative permeabilities at irreducible water saturation, residual oil saturation, displacement efficiency and incremental oil recovery after implementation of the EOR process, can be determined. The standard configuration can be upgraded with modules such as dual monitoring taps, a gas injection line, automatic fraction collector and air bath.

Maximum pore pressure :

• 700 bar (10,000 psi)

Maximum confining pressure :

• 700 bar (10,000 psi)

Maximum working temperature :

• 150°C

Core diameter :

• 1 inch
• 1.5 inches
• Other sizes upon request

Core length :

• 2 to 6 inches
• Other lengths upon request

Pressure taps :

• Optional

Position :

• Horizontal

Wetted parts :

• Hastelloy

Power supply :

• 220 VAC, 50 Hz

Air pressure requirements :

• 7 bar (100 psi)
