Benchtop Rotary Sample Splitter

Rotary sample splitter suitable for dividing dry, free-flowing samples into representative portions.
Suitable for all types of samples including segregated and fine materials.
Bench-type unit designed for small sample volumes (1L to 25L capacity).

Working Principle

• Material is fed through a gravity-fed hopper, assisted by a vibratory feeder.
• The sample is directed to a rotating distributor and divided into multiple portions.
• Splitting ratio is controlled by adjusting the speed of the vibratory feeder and rotating carousel.
• Low operating speed (0 to 50 RPM) ensures continuous and representative division.

Options :

• Hopper vibrator (optional)
• Different container divisions (as per requirement)

Setup Instructions :

Hopper Adjustment :

• Adjust hopper height using corner knobs based on material size

Rotary Carousel Adjustment :

• Set rotation speed to ensure proper distribution and reduce dust

Vibrator Feeder Adjustment :

• Adjust feeder speed to control material flow; may require hopper readjustment

Hopper Vibrator :

• Optional use to prevent clogging and sticking

Operating Instructions :

• Place containers properly on carousel
• Load material into hopper
• Turn on hopper vibrator (optional)
• Start carousel and set speed
• Adjust feeder speed
• Close lid and start feeder
• Run until all material is collected

Note: Do not adjust controls during operation to maintain accuracy

Sample capacity :

• 1L to 25L

Number of containers :

• 10

Container capacity :

• ~300 ml to 2.5L each

Material :

• Stainless steel (hopper and containers)

Rotary speed :

• 0 to 53 RPM

Vibratory feeder speed :

• 0 to 11 ft/min

Power supply :

• 110V or 220V
• 1 phase
• 50/60 Hz

Dimensions :

• 20″ (W) × 30″ (L) × 22″ (H)

Weight :

• 200 lbs (90 kg)

Hopper discharge :

• 2″ diameter

Tray size :

• 3″ tapering to 4″

• Suitable for fine and segregated materials
• Vibratory feeder prevents clogging and arching
• Variable speed control for feeder and carousel
• Interchangeable, self-aligning containers
• Full dust enclosure with dust extraction port (3″)
• Heavy-duty steel cart with locking casters and adjustable shelves
• Multiple container size options available
