Controlled temperature airbath Special core analysis Instruments

The Controlled temperature airbath Special core analysis Instruments are precision convection cells that provide uniform constant temperature for a wide range of applications. Access to the enclosure is through a hinged front door. A fan integrated into the air bath creates convective heat transfer while sensitive components are cooled by strategically placed heat exchangers. A digital temperature regulator provides an accuracy of ±0.5°C and the maximum achievable temperature is 175°C.

Temperature range :

• Ambient to 175°C

Temperature accuracy :

• ±0.5°C

Operating environment :

• 18°C to 30°C, 20 to 70% humidity

Controlled temperature airbath Special core analysis Instruments 700

Internal dimensions :

• 500 mm (D) × 700 mm (W) × 900 mm (H)

Overall dimensions :

• 670 mm (D) × 860 mm (W) × 1210 mm (H)

Power requirement :

• 220V, 50Hz, 2.2 kVA

Weight :

• 160 kg

Controlled temperature airbath Special core analysis Instruments 1000

Internal dimensions :

• 500 mm (D) × 1000 mm (W) × 900 mm (H)

Overall dimensions :

• 670 mm (D) × 1160 mm (W) × 1210 mm (H)

Power requirement :

• 220V, 50Hz, 3.2 kVA

Weight :

• 190 kg

Controlled temperature airbath Special core analysis Instruments 1300

Internal dimensions :

• 500 mm (D) × 1300 mm (W) × 900 mm (H)

Overall dimensions :

• 670 mm (D) × 1460 mm (W) × 1260 mm (H)

Power requirement :

• 220V, 50Hz, 4.2 kVA

Weight :

• 220 kg

Controlled temperature airbath Special core analysis Instruments 1900

Internal dimensions :

• 500 mm (D) × 1900 mm (W) × 1420 mm (H)

Overall dimensions :

• 700 mm (D) × 2340 mm (W) × 1710 mm (H)

Power requirement :

• 220V, 50Hz, 6.8 kVA

Weight :

• 420 kg
