Crusher

A robust and dependable high-capacity jaw crusher suitable for laboratory and plant applications.
The Model C Jaw Crusher is used by laboratories and processing companies to crush solid materials such as rocks or soil and ores. The material to be processed falls into the crushing chamber of the Crusher via a guide chute and is crushed by the crushing action of a static and a dynamic jaw plate until it passes the preselected gap of the crusher.

Dynamic frequency :

• 5.42 Hz

Dynamic loading – horizontal :

• ° 1.87 kN

Dynamic loading – vertical :

• ° 8.34 kN

Jaw inlet :

• 500 ° 300 mm

Mass :

• 3,500 kg

Max feed size :

• 250 mm (85% of jaw inlet)

Motor power :

• 22 kW, 3 phase

Product end size :

• 30 mm / 75 mm

Throughput at usual product size :

• 15,000 kg/h

Toggle speed :

• 325 strokes per minute

Usual product size :

• 30 mm

Dimensions :

• 1,190(L) ° 765(W)° 1,370(H) mm

• Quick and easy to clean due to front door access
• Stepless, reproducible gap-setting per hand-wheel
• Easy exchange of jaw plates and side liners
• Modular infeed hopper: removable, with splash back protection, batchloader or dosing plunger
• External control box with start/stop
