Cutting Mill (Motor power -1.5 Kw)

At the end of each milling the door can be opened to remove the knifes and easily clean the grinding chamber.
Rapid reduction of large particles
Quick and easy to clean
Full range of bottom sieves
Collector volume 5.000 ml

Application :

• The Cutting Mill can process a large variety of flexible, medium-hard, fiber and mixed products. It can be used for batch and continuous grinding with variable speeds for fast, efficient grinding.

Electrical details :

• 230V / 50 Hz

Motor power :

• 1.5 kW

Speed :

• 500 – 3000 rpm

Weight :

• 68 kg (without under-frame); 90 kg (with under-frame)

End-fineness :

• 250 °m

End-fineness adjustment :

• By interchangeable bottom sieves

Number of rotor knifes :

• 3

Number of stator knifes :

• 4

Max feed size :

• Up to 80 mm depending on sample

Max quantity :

• 5000 ml

Min quantity :

• 50 g
