Cutting Mill (Motor power -220 V)

It is possible to choose between different feed hoppers and different knifes from hardened steel, tungsten carbide or heavy metal-free-steel depending on the grinding material. At the end of each milling the door can be opened to remove the knifes and easily clean the grinding chamber.
Rapid reduction of large particles
Quick and easy to clean
Full range of bottom sieves
Interchangeable knives
The CM500 can handle samples of up to 30Kg/h

Application :

• The Cutting Mill is used for batch and continuous grinding of hard, soft to brittle and tenacious plastics among many other products like rubber, wood, grass, herbs etc.

Cutting Chamber :

• 130 ° 200 mm

Electrical Details :

• 3 ° 400 V / 50 Hz

Noise Emission :

• 85 dB (A)

Motor Power :

• 220 V

Rotor :

• 310 rpm

Rotor Diameter :

• 150 mm

Screen Size :

• 1–8 mm

Speed :

• 224 rpm

Suction Box Volume :

• approx. 6 L

Net Weight :

• 135 kg (only machine)

Gross Weight :

• 190 kg (only machine)

Net Dimensions : (W ° D ° H)

• approx. 390 ° 485 ° 375 mm

Gross Dimensions : (W ° D ° H)

• approx. 600 ° 600 ° 600 mm

Motor :

• 3-phase gear motor

Number of Rotor Knives :

• 9

Number of Stator Knives :

• 2

Max Quantity :

• Up to 30 kg/hour

Min Quantity :

• 50 g

Max Feed Size :

• Up to 100 mm (depending on sample)

End Fineness :

• 250 °m

End Fineness Adjustment :

• By interchangeable bottom sieves
