Cutting Mill (Motor power - 3 - 4 kW )

The processing material falls into the cutting chamber via a guide chute and is shredded by cutting between rotating and fixed knives until it passes an attached sieve as ground product. The sieve extends over the lower half of the grinding chamber and can be changed easily. Final particle size is determined by the selected sieve perforation aperture.
When the grinding process is finished the grinding chamber is fully accessible by unscrewing two hand screws and folding back the feeding hopper. The grinding chamber is fully accessible for quick and easy cleaning.

• Rapid reduction of large particles
• Quick and easy to clean
• Rapid sieve and knife changeover
• The Cutting Mill (Motor power – 3–4 kW) can handle samples of up to 60Kg/h

Application :

• The Cutting Mill (Motor power – 3–4 kW) is used to grind solid materials such as rubber, plastic, wood, foils and many other materials.

Cutting chamber :

• 230 mm

Electrical details :

• 3 ° 400V / 50 Hz

Motor power :

• 3 – 4 kW

Rotor diameter :

• ° 150 mm, length 200 mm

Speed :

• 280 rpm

Transport Data :

Net weight :

• 230 kg (only machine)

Gross weight :

• 250 kg (incl. packing, without accessories)

Features / Performance :

Number of rotor knifes :

• 3

Number of stator knifes :

• 2

Max quantity :

• Up to 60 kg per hour

Min quantity :

• 50 g

Max feed size :

• Up to 100 mm depending on sample

End-fineness :

• 500 °m

End-fineness adjustment :

• By interchangeable bottom sieves
