Cutting Mill (Motor power - 5.5 kW)

The material to be processed falls into the cutting chamber of the Cutting Mills via a guide chute. Then the product is shredded between rotating and fixed knives. The product passes the sieve as soon as it has reached the desired size. The sieve extends over the lower half of the grinding chamber and can be changed easily. Final particle size is determined by the selected sieve perforation aperture.

When the grinding process is finished the grinding chamber is fully accessible for quick and easy cleaning by unscrewing two hand screws and folding back the infeed hopper.

• Quick and easy to clean
• Full range of bottom sieves
• The Cutting Mill (Motor power – 5.5 kW) can handle samples of up to 150Kg/h

Application :

• The Cutting Mill (Motor power – 5.5 kW) is used by laboratories and processing companies for cutting granulate solid materials such as waste, wood and thermoplastics.

Electrical details :

• 3 ° 400V / 50 Hz

Motor power :

• 5.5 kW

Speed :

• 280 rpm

Number of rotor knifes :

• 12

Number of stator knifes :

• 2

Cutting chamber :

• 250 mm ° 250 mm

Rotor diameter :

• ° 195 mm

Quantity maximum :

• Up to 150 kg per hour

Quantity minimum :

• 100 g

Feed size maximum :

• Up to 250 mm depending on sample

End fineness :

• 1 mm (depending on material characteristics)

Net dimensions :

• Approx. 730 (W)° 925 (D)° 1730 (H) mm

Gross dimensions :

• Approx. 900(W)° 1025(D) ° 1930(H) mm

Net weight :

• 390 kg

Gross weight :

• 420 kg
