Disc Mill

Application :

• The Disc Mill Pulveriser is a simple, durable machine for fine grinding of soft to hard ores, alloys, rocks, ceramics, soils and similar materials.

Construction :

• The internal surface of the grinding chamber is smooth and easy to clean. The grinding chamber comprises one fixed and one rotating 200 mm diameter grinding disc turning about a horizontal axis. Internal surfaces are smooth faced and easily accessed and cleaned between samples.

Operating Principle :

• Operating capacity depends upon the disc gap setting, feed size and the crushing properties of the material being processed.

Standard Supply :

• 1.5 kW (3 phase) motor
• One fixed grinding disc
• One rotating grinding disc
• Stepless disc gap adjustment
• Sample collector

Optional Arrangement :

• The Disc Mill can be supplied mounted on a specially built bench complete with dust extraction hood for dust-free operation.

Typical Uses :

• Primary crushing
• Pilot plants
• Sampling stations

Approximate mass :

• 130 kg

Dust extraction hood :

• Available optional

Electrical requirements (3 phase) :

• 1.5 kW

Gap adjustment :

• Flexible setting

Max feed size :

• 20 mm

Product size :

• < 100 °m

Speed setting :

• 690 rpm (828 rpm at 60 Hz)

Throughput :

• Up to 150 kg/hr

Dimensions :

• 865 ° 420 ° 385 mm
