FBC New Fiber Optic Communication Trainer

Base Station & Fundamentals Module

Fiber Characteristics :

• Optoelectronic in Fiber technology :

• a. Receiver

• b. Transmitter

• Fiber Media types: Single-mode (ST), Multi-mode (SC)

• Fiber Cable Transmission :

• Attenuation and Loss

• Understanding Digital and Analog signal transmission over Fiber Optics cable:

• a. Data coding and decoder

• b. Multiplexing and De-multiplexing

• c. Modulation and Demodulation

• Fundamentals of Fiber Optic Transmitters Design

• Fundamentals of Fiber Optic Receiver Design

Fiber Optics Installation and Repair

• Splices, Connectors and terminations.
• Fiber Optic cable preparation:
• a. Cutting
• b. Polishing
• Connecting Fiber Optic cable.
• Attenuation in Fiber Optic cable.

Fiber Optics Applications

• Serial Communication between PCs over Fiber Optic media.
• Analog communication over Fiber Optic media.
• PC Network data communication over Fiber Media Kit.

Consists of :

• Fiber Optic Network Card, 1 port (2 PCs)
• Fiber Optic Cable 6m length (1 pair)
• Fiber Optic Loop Back Cable (1 pc)
• The Kit is designed for testing Fiber optic network cards, cables and connectors in PC Network Configuration.
