Flow through core cleaner laboratory and Oilfield instruments

A rapid and efficient core cleaning system based on controlled sequential solvent displacements at moderate pressures. The standard version is delivered with a single core holder but multiple can be integrated into the assembly upon request. Samples are placed in a quick release Hassler core holder which can be heated up to 80°C. Clean solvents are injected through the core via the constant rate-operable HPLC pump. The clean solvent can be pumped directly from any of the four tanks. After exiting the core, the solvent flows directly through a BPR and into a large capacity waste tank. Cores are considered clean when the effluent is clean.

Maximum confining pressure :

• 1,000 psi

Core diameter :

• 1.5" (other upon request)

Core length :

• Up to 3" (other upon request)

Fluid flow rate :

• 5 cc/min (recommended)

Wetted parts :

• Stainless steel

Electrical :

• 110-220 VAC, 50 or 60 Hz

Weight :

• 40 Kg

• Possibility to pump different solvents
• Constant injection flow for solvent
• Easy core loading and unloading operation
• Cleaning at pressure for high permeability sample
