Foam analyser system and trainers

Foam analyser system and trainers is an attractive EOR scheme in terms of cost, effectiveness, and environmental-friendliness. Foams mainly serve as mobility control or gas blocking agents. To optimize their effectiveness, the critical foam parameters should be studied at reservoir-representative conditions. The Foam analyser system and trainers permits this; foams are produced in a high pressure visual cell continuously monitored by a high-resolution image capturing system. A dedicated software then interprets the images and reports the following:

Physical Quantities Measured in Real Time:

• Gas flowrate
• Volume of the foam
• Volume of liquid in foam

Physical Quantities Calculated in Real Time:

• Volume of the foam
• Density of the foam
• Bikerman index
• Foam stability
• Foam expansion coefficient
• Foaming capability

Maximum working pressure :

• 10,000 psi (Stainless Steel Model)

Maximum working temperature :

• 150°C

Visual foam cell volume :

• 100 cc

Sight glass view :

• 230 mm × 8 mm

Wetted parts :

• Stainless steel

Power supply :

• 220 VAC, 50 Hz

Air pressure requirements :

• 7 bar (100 psi)
