Full size core end face grinder laboratory and Oilfield instruments

Tool designed to provide flat, parallel end-faces when sample geometry is critical e.g. for advanced rock property test. The tool can accommodate plug size and full size core samples up to 4 inches diameter.

Core Diameter :

• 1" to 4"

Core Length :

• 1" to 8" (other upon request)

Grinding wheel precision :

• +/- 0.001 inch (2.5 / 100 mm)

Grinding wheel diameter :

• 150 mm

Power supply :

• 220 VAC, 50 or 60 Hz

Motor power :

• 0,55 kw, 3,000 RPM

Weight :

• 40 kg

Volume :

• 600 x 500 x 500 mm
