Gas adsorption Isotherm System Unconventional reservoir Instruments

The system determines the adsorption isotherm for a combination of adsorbate (e.g. methane, CO2) and adsorbent (coal, shale, etc.). In other words, the apparatus evaluates at equilibrium the maximum volume of gas adsorbed onto an adsorbent at a specific temperature and pressure. This is achieved by means of the isothermal volumetric method in which the pressures and volumes of a reference and test cell held at constant temperature are continuously monitored.

The apparatus is fully automated, allowing computer-controlled gas injection, pressure monitoring and data acquisition. Up to four testing chambers can be integrated into the system to allow simultaneous and independent testing.

Maximum pressure :

• 10,000 psi

Maximum temperature :

• 175°C

Sample cell volume :

• 100 ml

Reference cell volume :

• 300 ml

Material :

• Stainless steel

Test gas supply :

• 3,000 psi

Helium gas supply :

• 3,000 psi

Required air pressure :

• 100 psi

Power supply :

• 110-220 VAC, 50/60 Hz

• Fully automated test
• System can be configured with two sample cells or multiple sample chambers
• Easy to use
