Gas hydrates autoclave system system and trainers

The Gas hydrates autoclave system system and trainers is a mercury-free device designed to study gas hydrate formation, dissociation and induction time by monitoring the pressure drop during hydrate formation. The apparatus also incorporates an image capturing system permitting visual investigations of the phenomenon. The system consists of a 250 cc isochoric hydrate cell rated up to 3,000 psi. The cell temperature, monitored by a thermocouple accurate to 0.1°C, is regulated by a thermostatic bath and cell pressure is surveilled by a highly accurate transducer. The two quantities are continuously displayed in the data acquisition system. A magnetically driven, speed-adjustable stirrer ensures a thorough and efficient agitation while an integrated stethoscopic camera captures experimental images.

Pressure :

• 3,000 psi

Volume :

• 250 cc

Temperature :

• -10°C to 60°C

Pressure accuracy :

• 0.1% Full Scale

Temperature accuracy :

• 0.1°C

Stirring mechanism :

• Magnetic drive

Stirring speed :

• up to 1000 RPM

Power supply :

• 220 VAC, 50 Hz

• Cost effective
• Accurate pressure and temperature measurements
• Video image capturing that allows for later retrieval
• Mercury free operations
