Glass fluid transfer vessel Special core analysis Instruments

The transparent fluid transfer vessel facilitates fluid transfer (mud, brine, oil, acid mixtures) into high-pressure, high-temperature accumulators located inside the air bath. The fluid in the container is displaced by pressurized air injected from the top of the vessel. The vessel comprises a glass tube braced by two end plugs fastened together with two aluminium tie bars. The glass tube is protected by an external polycarbonate tube in the event of glass failure. The top end plug can be easily removed for convenient liquid filling.

Maximum pressure :

• 100 psi

Volume :

• 1,500 cc

Material :

• Glass

Compatible fluids :

• Brine, oil, mud, drilling fluids and other process fluids

External polycarbonate safety protection tube :

• available

Removable top end plug for easy filling :

• available
