HTST/UHT Mini Pilot System Deluxe

Extends the range of continuous operation scaled-down units to 200 l/hr (30-100 l/hr for standard model). Combines full flexibility with comprehensive instrumentation demanded of research and development equipment with capability of aseptic packaging of processed product.

Extends the range of continuous operation scaled-down units to 200 l/hr (30-100 l/hr for standard model). Combines full flexibility with comprehensive instrumentation demanded of research and development equipment. Service unit contains services, controls and instrumentation required to operate tubular and plate heat exchangers with capability of aseptic packaging of processed product. Learn about HTST/UHT Mini Pilot System manufacturers for optimal educational outcomes..

• Feed pump: Progressive cavity variable speed pump
• Solids handling (soft): 10 mm
• Solids handling (hard): 4 mm
• Flow rate: 30-100 l/hr
• Discharge pressure: 24 bar (max)
• Pre-heat water system capacity: ~2-3 litres
• Pre-heat maximum temperature: 110°C
• External steam supply maximum temperature: 165°C
• Max product heating duty: 17kW
• Tubular heat exchanger: 10 tubes (2 preheat, 4 heating, 4 cooling)
• Tube diameter (product side): 8.1 mm
• Overall diameter: 22.0 mm
• Length (heated): 1.46 m
• Product volume: 1.0 l
• Material: 316 stainless steel
• Assembled test pressure: 30 bar
• Working pressure: 24 bar (maximum)
• Plate heat exchanger overall dimensions: 150 x 480mm
• Effective area per plate: 0.04m²
• Plate thickness: 0.6mm
• Product volume: 2.5 litres
• Plate material: 316 stainless steel
• Gasket material: Food grade Viton
• Max working pressure: 9.6bar
• Working temperature max: 110°C, min: -4°C
