Hydrates Kinetics Studies System system and trainers

A complete mercury-free instrument dedicated to gas hydrate kinetics studies. Specifically, the device allows the evaluation of parameters such as induction time and post-nucleation growth rate. It is also used to assess inhibitor kinetics for a diverse range of inhibitors (hydrates, anti-caking, emulsion, natural inhibitors, salts…). The system consists of a 250 cc isochoric hydrate cell rated up to 5,000 psi. The cell temperature, monitored by a thermocouple accurate to 0.1°C, is regulated by a thermostatic bath and cell pressure is surveilled by a highly accurate transducer. A magnetically driven, speed-adjustable stirrer ensures a thorough and efficient agitation. The torque required to drive the stirrer at a constant, preset speed is measured and utilized to deduce the sample’s viscosity.

Pressure :

• 5,000 psi

Volume :

• 250 cc

Temperature :

• -10°C to 100°C

Pressure accuracy :

• 0.1% Full Scale

Temperature accuracy :

• 0.1°C

Stirring mechanism :

• Magnetic drive

Power supply :

• 220 VAC, 50/60 Hz

• Very efficient stirrer with torque measurement
• Can be used to evaluate anti-caking inhibitors
• Accurate torque, pressure and temperature measurements
• Mercury free operations
