Interactive Panel

The interactive panels are designed to provide teachers with a tool to create interactive and attractive learning environments. These panels incorporate different teaching tools and internet connectivity.

ATENG 12043 — Interactive Panel

• Screen type: TFT LCD.
• Display definition: 4K UHD (3840 x 2160 @ 60 Hz).
• Screen ratio 16:9.
• Viewing angle: 178°.
• Color display: 1070 million.
• Response time: 8 ms.
• Refresh rate: 120 Hz.
• Contrast: 4000:1.
• Ambient brightness sensor.
• High hardness tempered anti-flash glass.
• Glass hardness: 7 (Mohs scale).
• Non-abrasive.
• Interactivity:
• Natural writing technology.
• 15 continuous touch points.
• Accuracy: 1 mm.
• Writing device and support included.
• Compatibility: Windows® 7 to 10, OS X® 10.8 to 10.11, macOS® Sierra 10.12.1 or later Linux® Ubuntu® 18.04 LTS, Chrome OS™.
• Connectivity:
• OPS.
• Three HDMI ports.
• Two USB-A 2.0 ports.
• One USB-A 3.0 port (for data transfer).
• Two USB Touch ports (Type B).
• LAN port in and out (RJ45).
• VGA.
• RS-232.
• CVBS.
• Microphone and headset (3.5 mm).
• Operating system Android™ Oreo 8.
• Hardware:
• 2 GB of RAM.
• Internal storage: 16 GB.
• CPU: Quad Core: (2) ARM Cortex A73, (2) ARM Cortex A53.
• GPU: ARM Mali-G51 MP2.
• Two speakers on the front (2 x 15W).
• Consumption in suspended state: ≤ 0.5W.
• Ultra-silent fan.
• Software license included.
• Environment conditions allowed:
• Operating temperature: 0 °C to 40 °C.
• Storage temperature: -15°C to 55°C.
• Operating humidity: 20 % to 80 %.
• Storage humidity: 20 % to 90 %.
• Includes WiFi module support and wall support.

Specifications

• C-ID-65I. Interactive Panel (65’’).
  65-inch diagonal interactive display.
• Screen dimensions: 1429 x 804 mm approx (56.3 x 31.7 inches approx.)
  65”
• Electrical power: ≤ 190 W.
• Panel dimensions: 1536 x 960 x 90 mm approx (60.5 x 37.8 x 3.5 inches approx.)
• Weight: 46 Kg approx (101 pounds approx.).
• C-ID-86I. Interactive Panel (86’’).
  86-inch diagonal interactive display.
• Screen dimensions: 1895 x 1066 mm approx (74.6 x 41.9 inches approx.)
  86”
• Electrical power: ≤ 390 W.
• Panel dimensions: 2018 x 1236 x 113 mm approx. (79.4 x 48.7 x 4.4 inches approx)
• Weight: 84 Kg approx (185 pounds approx.)
• C-ID-S. Holder for Interactive Panel (65/86’’).
  Metal support with wheels for 65 and 86 inch interactive panels.
• Manual height adjustment.
• Dimensions: 560 x 610 x 70 mm approx (22.04 x 24.01 x 2.75 inches approx.)
• Weight: 22 kg approx (48 pounds approx.)
• Specifications subject to change without previous notice, due to the convenience of improvement of the product.
