Jaw Crusher( End fineness: 2 mm)

Application :

• Superior Jaw Crusher engineered for rapid reduction of hard and brittle materials. Designed for laboratory use and field operations such as prospecting.

Construction :

• The Jaw Crusher ( End fineness: 2 mm) is a robust single-toggle type with one fixed jaw plate and one moving jaw plate. It is designed for smaller laboratories or remote operations and built with durable, serviceable components.

Performance :

• Can crush materials up to 85% of the jaw opening (130 mm ° 100 mm)
• Long-wearing and suitable for continuous use
• Toggle adjustment via jacking screw

Supply & Configuration :

• Free-standing floor-mounted unit
• Motor positioned at the rear of the main body
• Hinged inlet hopper
• Removable sample bucket
• Dust extraction point at the top of the machine

Power supply :

• 230V / 50 Hz

Rated power :

• 0.75 kW

Volume :

• 900 ml

Weight :

• 35 kg

Rotor :

• 6 / 12 / 24 teeth

Ring sieves :

• 200 °m – 6.00 mm

Speed setting :

• 10,000 – 18,000 rpm

Collecting pan :

• Standard

Safety clip :

• 2

Micro switch :

• Standard according to CE

• Quick and easy cleaning due to front door access

• Stepless, reproducible gap-setting by hand-wheel

• Easy exchange of jaw plates and side liners

• Modular infeed hopper: removable, with splash back protection, batch loader or dosing plunger

• External control box with start/stop

• End fineness: 2 mm

• Contamination-free crushing using 4 different grinding tools
