Jaw Crusher ( End fineness: 6 mm)

The Jaw Crusher (End fineness: 6 mm) is used for the rapid, effective crushing and pre-crushing of medium-hard, hard, brittle and tough materials. Its variety of materials offered, including heavy-metal free steel, its efficiency and safety makes it ideal for sample preparation in laboratories and industrial plants.
For small amounts of sample the Jaw Crusher (End fineness: 6 mm) is used batch-wise; for larger amounts it can be operated continuously. Control of the gap width and zero point adjustment allow for reproducible results.

Construction :

• Thanks to the modular construction of housing and frame this jaw crusher is suitable for a wide range of applications.

Approximate mass :

• 980 kg (gross)

Automatic lubrication :

• Optional

Central lubrication :

• Standard

Electrical requirements (3 phase) :

• 15 kW, 400/690V, 50 Hz

End-fineness :

• < 6 mm

Feed size :

• 350 ° 170 mm

Gap setting :

• 6 – 50 mm

Jaw inlet (mouth wide) :

• Custom

Jaw inlet (volume) :

• Custom

Throughput :

• 3500 kg/h

Toggle speed :

• 405 rpm

Dimensions :

• 1420 (L) ° 622 (W) ° 869 (H) mm

• Quick and easy to clean
• Adjustable gap-setting
• Easy exchange of jaw plates and side liners
• Modular infeed hopper: removable, with splash back protection, batchloader or dosing plunger
• External control box with start/stop
• End fineness: 6 mm
• Powerful 15 kW motor
• Low installation height (520 mm)
• Contamination free crushing
