Laboratory Process Chiller Deluxe

A recirculating process chiller suitable for both pilot plants and laboratories with small footprint giving high capacity. Food grade primary and secondary refrigerants compatible with modern and future food and beverage research centres.

A recirculating process chiller suitable for both pilot plants and laboratories with small footprint giving high capacity to cater for all ice/chilled water requirements. Food grade primary and secondary refrigerants compatible with modern and future food and beverage research centres are used.

• Refrigerant: R407C Freon
• Max ambient temperature: 32°C
• Typical cooling capacity: 10.8kW with outlet temperature of 0°C using 20% glycol solution
• Process pump head: 6 bar max
• Process pump flow rate: 4.8 m³/hr at 3.7 bar
• Ingress protection rating: 54
