Modular Miniature Scale HTST/UHT Process System Deluxe

A modular HTST/UHT processing system designed to treat products at flow rates of 10-60 l/h. Interchangeable modules for direct heating (steam injection) or indirect heating (tubular, plate or scraped surface heat exchangers), aseptic processing, upstream or downstream homogenisation and additional chilling.

A modular HTST/UHT processing system designed to treat products at flow rates of 10-60 l/h. Interchangeable modules for direct heating (steam injection) or indirect heating (tubular, plate or scraped surface heat exchangers), aseptic processing, upstream or downstream homogenisation and additional chilling.

• Feed pump: Progressing cavity variable-speed pump
• Particulate handling: 0.8mm
• Fibre handling: 25mm
• Flowrate: 10-120l/h (max)
• Plate heat exchanger nominal/processing flowrate: 20l/h / 10-60l/h
• Plate overall dimensions: 75 x 115mm
• Effective diameter: 3.0mm
• Plate thickness: 0.5mm
• Wetted perimeter: 153.0mm
• Plates: 316 stainless steel
• Gaskets: Food-grade silicone
• Working pressure: 10 bar (max)
• Tubular heat exchanger tube diameter (product side): 8.1mm
• Overall diameter: 15.8mm
• Material: 316 stainless steel
• Assembled test pressure: 15 bar
• Working pressure: 10 bar (maximum)
• Scraped surface heat exchanger nominal/processing flowrate: 20l/h / 10-40l/h
• Heat transfer area: 0.045m²
• Scraper blades: 4 PEEK scrapers on stainless steel shaft
• Barrel working pressure: 10 Bar
• Utility requirements: Mains water 5 l/min @ 2 bar, Electricity 400V/3ph/50-60Hz/30 amp, Compressed air 6 bar, Steam 6 bar (estimated 15 kg/h)
