Mortar Grinder

Application :

• The Mortar Grinder Model is used to reproducibly grind, homogenize and mix a wide range of solid materials in dry, wet or cryogenic conditions.

Working method :

• The material to be processed falls into the pulverizing area between the mortar and pestle by top feeding via the opening at the inlet cover. The material is then pulverized and mixed between the mortar inner surface area and the bottom of the pestle.

Adjustment & Control :

• To match the necessary top pressure with the requested end fineness and the breaking behaviour of the sample, the Mortar Grinder is equipped with:
• Adjustable top pressure mechanism with scale
• Variable speed setting: 50–130 rpm
• Flexible scraper setting
• Only the combination of these three key adjustment features allows a wide range of sample preparation tasks to be achieved.

Cleaning & Maintenance :

• No other grinding system is easier to clean than the MG100 Mortar Grinder. When the grinding process is finished, the mortar and pestle can be taken out with a bayonet lock for quick cleaning of the grinding tools.

Processes :

• Dry grinding
• Wet grinding
• Ultra-fine grinding
• Cryogenic grinding
• Mixing
• Cell disruption for DNA/RNA extraction

Electrical details :

• 100–120 / 200–240 Volt, 50/60 Hz

Motor power :

• 200 Watt

Speed :

• 40 – 150 rpm adjustable

Net dimensions :

• 700(W) ° 750(D) ° 700 (H)mm

Gross weight :

• 44 kg

Net weight :

• 53 kg

Working principle :

• Friction

End fineness maximum :

• 10 – 20 °m

Feed size maximum :

• 8 – 10 mm depending on sample

Grinding time setting :

• 1 – 99 min. / continuous

Pestle adjustment :

• By adjustment wheel

Pressure setting :

• By scale adjustable

Quantity maximum :

• 200 ml

Quantity minimum :

• 10 ml

Scraper adjustment :

• By adjustment wheel

Speed setting :

• 50 – 130 rpm
