Pellet Press

Solid, high-quality pellets are an important precondition for reliable and meaningful XRF analysis. Pellet Presses are used for preparation of pellets for spectral analyses.

Can be used construction materials, metallurgy, geology, ceramics plastics, environment, recycling, chemistry, glass, etc. fields.

Spare Parts & Accessories :

• Pellet Mould - 40mm

Construction :

• The Pellet Press is a compact bench unit with particularly simple and safe operation.
• Pellet Press has 4-side closed Plexiglass Covers and Aluminum Frame.

Pressure Capacity :

• With a pressure force of 20 ton it is ideally suited for the preparation of solid samples for XRF analysis.
• Maximum pressure is 20 ton.
• It offers precise loading with double-flow pump.
• The pellets produced are of high quality and characterized by their high degree of stability.

Models :

• Two models are available as Manual or Digital.

Manual Pellet Press :

• On the Manual Pellet Press, the piston pressure can be read off from the clearly visible manometer scale.

Digital Pellet Press :

• On the Digital Pellet Press, the measurements are carried out very precisely thanks to the load cell.
• Digital Pellet Press consists of a digital LCD screen which the load values can be read sensitively.

Pellet Mould :

• Pellet Mould is manufactured as 40 mm from special tool-steel.
• Its inner surface is grinded and hardness is 60 HRC.
• Pellet Mould should be ordered separately.
