Pellet Press - Motorized

The motorized Hydraulic Pellet Press is designed for frequent and reproducible preparation of small powder samples. The press unit is suitable for free-standing use on a laboratory bench.

Applications :

• Suitable for different types of powder samples such as:
• Ground soil
• Various laboratory powders

Pressing Range & Control :

• Pressing pressure freely selectable between 200 kg to 5 tons.
• Pressure can be adjusted in steps of 0.01 tons using the digital display.

Construction & Design :

• Compact motorized laboratory press.
• Made from solid stainless steel and aluminium construction for high durability and quality.

Operation :

• Easy to operate.
• Designed for consistent and repeatable pellet preparation in laboratory environments.

Width between pillars :

• 150 mm

Min. / Max. clear height :

• 52 mm / 142 mm

Display :

• Digital

Spindle diameter :

• 35 mm

Max. way of spindle :

• 102 mm

Piston diameter / max. lifting :

• 105 mm / 22 mm

Power supply :

• 110×230 V / 50–60 Hz

Weight :

• 40 kg

Dimensions (W × D × H) :

• 370 × 300 × 538 mm
