Pneumatic Disc Mill

Pneumatic Disc Mill is used for pulverizing the soil, rock, cement, limestone, ceramic, metal oxides etc. rigid fragile materials.

Dimensions (cm) :

• Pneumatic Disc Mill, Standard - 100x75x130
• Pneumatic Disc Mill, Equipped with wheels - 100x75x130
• Pneumatic Disc Mill, PLC Time Controlled - 100x75x130
• Pneumatic Disc Mill, PLC Time and Speed Controlled - 100x75x130

Power Supply :

• Pneumatic Disc Mill, Standard - 380 V, 50-60 Hz, 3 ph
• Pneumatic Disc Mill, Equipped with wheels - 380 V, 50-60 Hz, 3 ph
• Pneumatic Disc Mill, PLC Time Controlled - 380 V, 50-60 Hz, 3 ph
• Pneumatic Disc Mill, PLC Time and Speed Controlled - 380 V, 50-60 Hz, 3 ph

Grinding Set :

• Supplied with 800 cc Standard Steel Grinding Set.
• 100 cc and 1000 cc Steel Grinding Set is available as an optional and should be ordered separately.

Working System :

• Loss of material is minimum during the pulverizing.
• The Steel Grinding Set vibrates the Grinding Jar and Pulverizing is carried out by means of a disk in the Jar.
• With the belt pulley system, achieves three-dimensional vibration by moving the shaft.

Feed Size and Fineness :

• Material Feed size is –20 mm and the final fineness for % 85 of grinded material is < 0.075 mm depending on feed material and instrument configuration/settings.

Construction :

• The Pneumatic Disc Mill is designed the way that as dust will not leak out during operation.
• The noise emission level according to the working atmosphere is maximum 85 dB.
• Internal body is covered with fireproof acoustics noise insulation material and dust and dirt entry onto the materials such as motor and shaft are prevented.
• The cover mechanism has been designed appropriately in terms of occupational health and safety.

Safety and Cover System :

• The Pneumatic Disc Mill has a locking mechanism and a cover for sound insulation.

Control System :

• There is an Adjustable Timer.

Safety System :

• The Pneumatic Disc Mill stop when the door opens or the air pressure decrease automatically.

Models

4 models are available :

• Pneumatic Disc Mill, Standard has standard specifications.
• Pneumatic Disc Mill, Equipped with wheels is Wheeled in addition to the standard model.
• Pneumatic Disc Mill, PLC Time Controlled is Wheeled in addition to the standard model. It has PLC Time Controlled Digital Touch Screen. Time periods at Test values can be saved in the memory and can be selected quickly during the Test.
• Pneumatic Disc Mill, PLC Time and Speed Controlled is Wheeled in addition to the standard model. It has PLC Time and Speed Controlled Digital Touch Screen. Time periods and Speed at different Test values can be saved in the memory and can be selected quickly during the Test.

Optional Equipment :

Safety Lock, Lifter and Air Compressor should be ordered separately.

Spare Parts & Accessories :

• Steel Grinding Set 100cc
• Steel Grinding Set 800cc
• Steel Grinding Set (High Quality Tool Steel) 800cc
• Steel Grinding Set (High Quality Tool Steel) 1000cc
• Safety Lock
• Lifter
