Pressure Filter Device

Cylinder Reservoir

• The Cylinder Reservoir of Pressure Filter Device which made the filtration is manufactured from 304 stainless steel.
• The Cylinder Reservoir capacity is 20 lt and the top and bottom surfaces are smooth.

Filtration System

• The bottom part of the chamber where the filter paper is placed provides the evacuation of water and liquid by means of special grooves.

Cover System

• There is a cover that compress from the top of the Cylinder Reservoir of Pressure Filter Device which made the filtration.
• Silicone gaskets are used to provide the sealing under this cover.

Pressure System

• There is a gauge on the top of cover showing a pressure of at least 10 bar.
• At the same time there is an inlet which discharges the air in the compressor.
• There is a safety valve that discharges in high pressure applications.

Air Transfer System

• To transfer the air in the compressor, a pressure resistant 3 m special hose is used.
• The other end of this hose has an connecting apparatus for air compressor.
• There is a valve through which the air can be evacuated from the cover.

Material Removal

• At the last stage, there is a handle which can lift a little the Cylinder Reservoir to get the material that on the filter paper.

Liquid Outlet

• There is a valve on the underside of the device to flow the filtered liquid from the filter paper.

Mobility

• The device is wheeled.
• Wheels can be locked.
