Proppant crush tester Reservoir stimulation Matrix acidizing Instruments

The Proppant crush tester Reservoir stimulation Matrix acidizing Instruments is designed to execute proppant crush-resistance tests in accordance with ISO 13503-2 standard methodologies for determining the extent of proppant crushing under specified closure stresses. Equipped with a 50 mm (2 in) diameter piston, the device can generate pressures up to 20,000 psi. The apparatus operates at a controlled piston displacement rate, capable of achieving loading rates up to 2,000 psi per minute.

The primary components of the system include a servo-controlled load frame and a cylindrical proppant cell. Continuous monitoring of the applied load is performed and fed back into the controller. This real-time feedback automatically adjusts the crosshead motion to maintain the targeted loading rate throughout the test.

Standards compliance :

• ISO 13503-2, API 56, API 58 & API 60

Maximum crush stress :

• 20,000 psi

Operating temperature :

• Ambient

Cell inside diameter :

• 2.0 inches (50.8 mm)

Cell outside diameter :

• 3.5 inches (89 mm)

Piston height :

• 3.5 inches (89 mm)

Material :

• Stainless steel

Power supply :

• 220 VAC, 50 or 60 Hz

• Fully automated apparatus
• Rapid, accurate and reproducible data
• Precision load control
• Improved test consistency and accuracy
