Radial core slabbing saw laboratory and Oilfield instruments

Versatile diamond impregnated radial blade utilised either to slab core samples in two halves or to trim full diameter rock samples. The standard machine comes with a worktable, blade guard, motor to power the saw, core clamp assembly for holding core, sample trolley on ball bearing guide, coolant feeding system, coolant recovery pan and diamond impregnated saw blade. The coolant recirculation system is also available.

Saw blade diameter :

• 400 mm (16'')

Maximum cutting depth :

• 125 mm (5")

Max core length :

• 300 mm

Compatible coolants :

• Water and oil

Power supply :

• 220 VAC, 50 or 60 Hz

Weight :

• 100 kg
