Recovery still for solvent laboratory and Oilfield instruments

The recovery still separates crude oil from solvents used in extraction processes. This procedure is achieved via the fractional distillation method, possible as a result of the difference in boiling point temperature of the two liquids. The apparatus consists mainly of an insulated boiler tank electrically heated from the bottom, and a water circulating condenser. Dirty solvent is manually poured into the tank whereas the condensed toluene vapor drips into a separate container. The treatment tank’s effortless removal facilitates the cleaning of slug deposits. Although the apparatus is explosion-proof, it should be installed in a hazard-free environment.

Recovery :

• 95 %

Recovery time :

• 3 to 5 hours for 20 litres

Max temperature :

• 200°C

Tank capacity :

• 20 litres, other upon request

Protection :

• IP 66

Material :

• stainless steel

House water consumption :

• 50 litres per hour

Power supply :

• 220 VAC 50 Hz, 2,500 W

Dimensions :

• 850 x 1000 x 1000 mm

Weight :

• 165 Kg
